MT4000 Series

The MT4000 Series is a newly designed upright biological compound microscope system. Ergonomically designed, precisely manufactured and simple to use stage and coarse and fine controls. To meet the demands of researchers and clinical laboratory specialists. The MT4000 Series was to develop to provide functionality and operational ease. Viewing high quality images, sample changing and photomicroscopy are all conducted with ergonomics in mind. High luminescent LED illumination reduces need for frequent bulb replacement but still provide rugged durability and long life span.

Click on the image to download the brochure

The MT4000 Microscopes features include:

• Compact Space Saving Footprint design with ergonomics in mind

• Infinity Corrected Optical System (ICOS™) with all newly designed Planachromatic optics

• Comfortable Siedentopf-type Binocular and Trinocular Viewing heads

• Optional Ergonomic tilting binocular head- Adjustable vertically from 10°to 50° degrees

• Ceramic Coated Stage with Ergonomically Placed Low Position Drop down Control

• Parfocalled Microscope Objectives

• Tension adjustment control with Coaxial knobs

• Low Positioned Ergonomic Coaxial Focus Control

• Low Positioned Ergonomic Coaxial Focus Control

• Smooth Operating Ergonomic Quintuple Nosepiece

• Brightfield and Phase Contrast Observation modes available

• Super Bright LED Koehler illumination, lambertian design

• Integrated 30-Watt Halogen Transmitted illumination System on selected Brightfield and Phase Contrast Models

• Abbe and Zernike Phase Contrast Condensers available

• Integrated Automatic Voltage Sensing Power Supply with localized power cord

• Rear Cord Wrap for easy storage

• Wide Range of Filters and Accessories
