MT4000V Series

The MT4000V “Veterinary Series” from Meiji Techno is a preconfigured compound biological microscope line tailored for the needs of veterinary practices—ideal for routine in-house diagnostics and training. Designed to be ready out of the box, it combines a wide field of view with a smooth, precise mechanical stage, giving clinicians confident sample navigation and fast, repeatable results in a compact, professional package.

Optically, the MT4000V is equipped with a full suite of infinity-corrected U.Planachromat objectives: 4×, 10×, 20×, 40×, and S100× (oil immersion). An Abbe condenser (NA 1.25) supports crisp, high-contrast imaging, while coarse and fine focus controls with a stage lock and tension adjustment enable ergonomic, consistent focusing. Illumination is provided by a transmitted LED or halogen base with auto-voltage sensing for reliable performance in varied environments. Together, these features deliver a dependable, practice-ready system built for everyday veterinary microscopy.

Click on the image to download the brochure

The MT4000V Series Microscopes features include:

• Compact Space Saving Footprint design with ergonomics in mind

• Infinity Corrected Optical System (ICOS™) with all newly designed Planachromatic optics

• Comfortable Siedentopf-type Binocular and Trinocular Viewing heads

• Optional Ergonomic tilting binocular head- Adjustable vertically from 10°to 50° degrees

• Ceramic Coated Stage with Ergonomically Placed Low Position Drop down Control

• Parfocalled Microscope Objectives

• Tension adjustment control with Coaxial knobs

• Low Positioned Ergonomic Coaxial Focus Control

• Low Positioned Ergonomic Coaxial Focus Control

• Smooth Operating Ergonomic Quintuple Nosepiece

• Brightfield and Phase Contrast Observation modes available

• Super Bright LED Koehler illumination, lambertian design

• Integrated 30-Watt Halogen Transmitted illumination System on selected Brightfield and Phase Contrast Models

• Abbe and Zernike Phase Contrast Condensers available

• Integrated Automatic Voltage Sensing Power Supply with localized power cord

• Rear Cord Wrap for easy storage

• Wide Range of Filters and Accessories
